Thin Wall Heat Shrink Tube 2:1 Commercial Grade (GLC)

About Thin Wall Heat Shrink Tube 2:1 Commercial Grade (GLC)

GLC is Gala's commercial-grade thin-wall heat-shrink tube. It is a flexible polyolefin tube with a 2:1 shrink ratio: when heated it recovers to half its supplied diameter and grips the wire, terminal, component or busbar underneath, giving electrical insulation and mechanical protection in one step.

Typical uses are light-duty wire harnessing in electrical and electronic equipment, insulating and protecting in-line components, strain relief where wires meet terminals, and insulating busbars in switchgear. Gala rates GLC for electrical insulation up to 3.3 kV.

Seventeen sizes run from GLC 6.0/3.0 to GLC 100/50.0. The code gives the minimum supplied inside diameter and the maximum recovered inside diameter in mm, and recovered walls run from 0.56 mm on the small sizes to 1.27 mm on the large ones. To choose a size, the supplied diameter must pass over the largest part of the job and the recovered diameter must be smaller than the smallest part. Tube is supplied on spools (100 m for sizes up to 20 mm, 50 m and 25 m above that) or in boxes of 1.2 m cut lengths. The standard colour is black. Shrink with a hot-air tool or a gentle torch flame.

GLC is the general commercial grade. Where a flame-rated tube is specified, Gala's GSC thin-wall tube is listed separately.

Manufactured by Gala in India. Datasheet and size selection on request.

Specifications

• Brand: Gala
• Product type: Thin wall heat shrink tube, 2:1, commercial grade
• Material: Heat-shrinkable polyolefin
• Colour: Black (standard)
• Voltage rating: Up to 3.3 kV (Gala rating)
• Operating temperature: -55 deg C to +125 deg C
• Shrink ratio: 2:1
• Size range: 6.0 to 100 mm supplied ID; 3.0 to 50 mm recovered ID
• Wall type / thickness: Thin wall, 0.56 mm to 1.27 mm after recovery (+/-10%)
• Standards tested to: Test methods quoted on Gala's datasheet - ASTM D638, ASTM D570, ASTM D2671, ASTM D150, ASTM D257
• Application: Light-duty wire harnessing, in-line component insulation, strain relief, busbar insulation in switchgear
• Installation: Hot-air tool or torch
• Country of origin: India
• Tensile strength: 10 N/mm2 min (ASTM D638)
• Elongation at break: 200% min (ASTM D638)
• Water absorption: 0.15% max (ASTM D570)
• Dielectric strength: 15 kV/mm min (ASTM D2671)
• Low temperature flexibility: -55 deg C for 4 h, no cracking
• Packing: Spools of 100, 50 or 25 m by size, or boxes of 1.2 m cut lengths (200 to 5 pieces per box)

Sizes

• GLC 6.0/3.0 | wall 0.56 | 100 m | 200 per box
• GLC 7.0/3.5 | wall 0.56 | 100 m | 200
• GLC 8.0/4.0 | wall 0.56 | 100 m | 175
• GLC 10.0/5.0 | wall 0.56 | 100 m | 150
• GLC 12.7/6.35 | wall 0.56 | 100 m | 120
• GLC 14.0/7.0 | wall 0.69 | 100 m | 100
• GLC 16.0/8.0 | wall 0.69 | 100 m | 100
• GLC 18.0/9.0 | wall 0.69 | 100 m | 80
• GLC 20.0/10.0 | wall 0.78 | 100 m | 65
• GLC 25.0/12.5 | wall 0.78 | 50 m | 40
• GLC 30.0/15.0 | wall 0.87 | 50 m | 30
• GLC 40.0/20.0 | wall 0.97 | 50 m | 20
• GLC 50.0/25.0 | wall 0.97 | 25 m | 15
• GLC 60.0/30.0 | wall 0.96 | 25 m | 10
• GLC 70.0/35.0 | wall 1.10 | 25 m | 10
• GLC 80.0/40.0 | wall 1.27 | 25 m | 10
• GLC 100/50.0 | wall 1.17 | 25 m | 5

Applications: Wire harness makers, electrical and electronic equipment manufacturers, switchgear and panel builders, OEM assembly lines, electrical contractors and maintenance teams
