Heat Shrink Semi-Conductive Tube for MV Cable Joints (GCT)
Heat Shrink Semi-Conductive Tube for MV Cable Joints (GCT)

Heat Shrink Semi-Conductive Tube for MV Cable Joints (GCT)

MOQ : 1 Piece

Heat Shrink Semi-Conductive Tube for MV Cable Joints (GCT) Specification

  • Installation Guideline
  • Propane torch, as part of the joint build-up
  • Size
  • 30 to 180 mm supplied ID; 10 to 55 mm recovered ID
  • Product Type
  • Heat shrink semi-conductive tube (insulation screen for cable joints)
  • Rated Voltage
  • For cable joints up to 33 kV (36 kV equipment)
  • Thickness
  • 2.5 mm to 3.0 mm after recovery (+/-10%)
  • Application
  • Insulation screen over connector insulation in MV joints on XLPE, PVC and PILC cables
  • Usage & Applications
  • Insulation screen over connector insulation in MV joints on XLPE, PVC and PILC cables
  • Color
  • Black
  • Material
  • Thermally stabilised cross-linked semi-conductive polymer



About Heat Shrink Semi-Conductive Tube for MV Cable Joints (GCT)

In a medium-voltage straight-through joint, the conductor connector is covered with insulation, and that insulation then needs an outer semi-conductive screen, just like the cable on either side, so the electric field stays inside the insulation. Gala's INSULTUBE Semi-Conductive tube (code GCT) provides that screen.

The tube is made from a thermally stabilised, cross-linked semi-conductive polymer. It is shrunk over the joint's insulation build-up and overlaps the cable's own screen on both sides, so the screen is continuous across the joint. It is used in joints on plastic-insulated (XLPE, PVC) and paper-insulated cables up to 33 kV (36 kV equipment), under the joint's metallic screen and outer protection.

Sizes on Gala's chart run from GCT 30/10 to GCT 180/55; the first figure is the minimum supplied inside diameter and the second the maximum recovered inside diameter, in mm, with recovered walls of 2.5 to 3.0 mm. Shrink with a soft propane flame.

Where one tube should carry both the insulation and the screen, Gala also makes a co-extruded double layer tube (GDLT), listed separately.

Manufactured by Gala in India. Datasheet and size selection on request.

Specifications

  • Brand: Gala
  • Product type: Heat shrink semi-conductive tube (insulation screen for cable joints)
  • Material: Thermally stabilised cross-linked semi-conductive polymer
  • Colour: Black
  • Voltage rating: For cable joints up to 33 kV (36 kV equipment)
  • Size range: 30 to 180 mm supplied ID; 10 to 55 mm recovered ID
  • Wall type / thickness: 2.5 mm to 3.0 mm after recovery (+/-10%)
  • Application: Insulation screen over connector insulation in MV joints on XLPE, PVC and PILC cables
  • Installation: Propane torch, as part of the joint build-up
  • Country of origin: India

Sizes

  • GCT 30/10 | D 30 | d 10 | T 2.5
  • GCT 40/12 | D 40 | d 12 | T 2.5
  • GCT 50/16 | D 50 | d 16 | T 2.5 (printed "GCT 40/12" a second time on the old page)
  • GCT 75/22 | D 75 | d 22 | T 2.5
  • GCT 90/26 | D 90 | d 26 | T 2.5
  • GCT 115/34 | D 115 | d 34 | T 3.0
  • GCT 140/42 | D 140 | d 42 | T 3.0
  • GCT 160/50 | D 160 | d 50 | T 3.0
  • GCT 180/55 | D 180 | d 55 | T 3.0

Applications: Cable jointing contractors, heat-shrink joint kit assemblers, power distribution utilities, industrial MV networks, cable repair teams
