PVC Terminal Insulation Cap for Cable Lugs (TERMICAP TCV)

About PVC Terminal Insulation Cap for Cable Lugs (TERMICAP TCV)

TERMICAP is Gala's flexible PVC insulating cap for wire-end terminals and cable lugs crimped onto power cables. Once a lug is crimped, its barrel and the bare conductor next to it are left exposed. The cap slips over the crimp and the end of the cable insulation, insulating the bare metal and protecting it against accidental contact.

The caps are made in blue, yellow, red, black, white and green, so they also serve to identify phases, neutral and earth at a glance in panels, switchboards, motor terminal boxes and distribution boards. They are pushed on by hand and need no heat or tools.

Twelve standard sizes, TCV 12 to TCV 3251, cover narrow-end diameters from 3.2 mm to 30 mm and lengths from 15 mm to 79 mm, so the range takes small control-wire terminals through to large power-cable lugs. Each cap is a stepped cylinder: a narrow closed section over the lug barrel and a wider section over the cable insulation. Gala also develops custom sizes, shapes and colours to the customer's requirement.

Manufactured by Gala in India. Datasheet and size selection on request.

Specifications

• Brand: Gala
• Product type: Terminal insulation cap, push-on (not heat-shrinkable)
• Material: Flexible PVC
• Colour: Blue, yellow, red, black, white, green
• Operating temperature: -20 deg C to +115 deg C continuous
• Size range: 12 sizes; narrow-end diameter 3.2 to 30 mm, length 15 to 79 mm
• Application: Insulating and colour-coding crimped cable lugs and wire-end terminals
• Installation: Pushed over the crimped terminal by hand
• Country of origin: India
• Tensile strength: 12 N/sq mm minimum (ASTM D638)
• Elongation: 350 % minimum (ASTM D638)

Sizes

• TCV 12 | D1 3.2 | D2 3.5 | D3 3 | L 15 | F 8
• TCV 21 | D1 3.5 | D2 4.5 | D3 3.8 | L 18 | F 10
• TCV 50 | D1 4.5 | D2 5.5 | D3 4.5 | L 21 | F 10
• TCV 53 | D1 5 | D2 6 | D3 5 | L 25 | F 10
• TCV 60 | D1 8 | D2 10 | D3 8 | L 27 | F 13
• TCV 221 | D1 9.5 | D2 12 | D3 8 | L 30 | F 16
• TCV 381 | D1 12 | D2 14 | D3 10 | L 35 | F 18
• TCV 601 | D1 14 | D2 16.5 | D3 14 | L 42 | F 23
• TCV 100 | D1 18 | D2 22 | D3 16 | L 54 | F 26
• TCV 501 | D1 22 | D2 24 | D3 22 | L 67 | F 33
• TCV 2501 | D1 26 | D2 37 | D3 26 | L 79 | F 38
• TCV 3251 | D1 30 | D2 37.5 | D3 30 | L 78 | F 38
• All in mm. D1 narrow (closed) section, D2 wide section inner diameter, D3 open mouth, L overall length, F length of the narrow section. Source: GSF BUSCAP and TERMICAP catalogue sheet, Issue 2, February 2024 (see Ask GSF on the chart's oddities).

Applications: Panel builders, switchboard and distribution board manufacturers, motor and control panel makers, cable harness and assembly shops, electrical contractors, transformer and switchgear manufacturers
